Ibanez builds guitars for players of all levels—from beginners to the most demanding masters of the instrument. Regardless of price, Ibanez always strives to offer the absolute best sound, style, and playability in its class. The Standard series incorporates all the staples the Ibanez brand is famous for, such as fast necks, floating trems, and high-octane distortion in a package that is available and accessible to most players.
Features
F106 bridge
The F106 bridge enriches sustain. String height adjustment can be done easily and independently.
Jatoba Fretboard
Jatoba has a reddish brown color which produces a rich mid range with a crisp high end.
Wizard III Maple neck
Ibanez's thin, flat and fast Wizard neck is strong and sturdy and offers unlimited playability and features a two-octave 24-fret fretboard for a wide tonal range.
Flamed Maple top / Meranti body
The Flamed Maple top flaunts a beautiful wood grain. The Meranti body provides a scooped mid-ranged sweet tone.
Quantum H-H pickups
The Quantum pickups have a quick low-end response to picking and are able to capture fast passages with precise note definition, while delivering a full-bodied mid-to-high range.
Technical Specifications
- Neck Type: Wizard III
- Neck Material: Maple neck
- Body Top Material: Flamed Maple top
- Body Material: Meranti body
- Fretboard: Jatoba fretboard
- Inlays: Off-set white dot inlay
- Frets: Jumbo frets
- Fret Count: 24
- Bridge: F106 bridge
- Strings: D'Addario® EXL110
- String Spacing: 10.5mm
- Neck Pickup: Quantum (H) neck pickup (Passive/Ceramic)
- Bridge Pickup: Quantum (H) bridge pickup (Passive/Ceramic)
- Factory Tuning: 1E, 2B, 3G, 4D, 5A, 6E
- String Gauge: .010/.013/.017/.026/.036/.046
- Hardware Color: Black
- Scale Length: 25.5"
- Nut Width: 43mm
- Fret Width at 24 Fret: 58mm
- Neck Thickness at 1st Fret: 19mm
- Neck Thickness at 12th Fret: 21mm
- Radius: 400mmR
RGA42FM's Switching system diagram
When the pickup selector switch is in neck position, the neck pickup is selected. When the switch is between neck and center position, the neck humbucker is selected and is in parallel. When the switch is in center position, both neck and bridge pickups are selected. When the switch is in between center and bridge position, bridge side of the neck pickup and neck side of the bridge pickup are selected. When the switch is in bridge position, the bridge pickup is selected.
RGA42FM's control diagram
With the guitar held in the playing position, there is one knob and one switch along the lower edge of the body. Closest to the neck is the five-way pickup selector switch. Closer to the input jack is the tone knob. The volume knob is located right above the five-way pickup selector switch.
